Mainboard Gigabyte B760M DS3H AX DDR4

Đóng
  • Bài viết đánh giá
Thương hiệu Gigabyte
Chipset
B760
Hỗ trợ Socket LGA 1700
Số khe ram 4 Slot DDR4
Lan Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
Kết Nối Không Dây
  • WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
  • Bluetooth 5.2
  • Support for 11ax 80MHz wireless standard and up to 1.2 Gbps data rate
Internal I/O Connectors
  • 1 x 24-pin ATX main power connector
  • 1 x 8-pin ATX 12V power connector
  • 1 x CPU fan header
  • 3 x system fan headers
  • 2 x addressable LED strip headers
  • 2 x RGB LED strip headers
  • 2 x M.2 Socket 3 connectors
  • 4 x SATA 6Gb/s connectors
  • 1 x front panel header
  • 1 x front panel audio header
  • 1 x S/PDIF Out header
  • 1 x USB Type-C® header, with USB 3.2 Gen 2 support
  • 1 x USB 3.2 Gen 1 header
  • 2 x USB 2.0/1.1 headers
  • 2 x Thunderbolt™ add-in card connectors
  • 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
  • 1 x serial port header
  • 1 x reset button
  • 1 x Q-Flash Plus button
  • 1 x reset jumper
  • 1 x Clear CMOS jumper
Độ Phân Giải Độ phân giải tối đa 7680 x 4320
Bios
  • 1 x 256 Mbit flash
  • Use of licensed AMI UEFI BIOS
  • PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Hệ Điều Hành
  • Support for Windows 11 64-bit
  • Support for Windows 10 64-bit
Form Factor
Micro ATX Form Factor 24.4cm x 24.4cm

Đặc Điểm Của Mainboard Gigabyte B760M DS3H AX DDR4

  • Intel® Socket LGA 1700:Support 13th and 12th Gen Series Processors
  • Unparalleled Performance:Hybrid 6+2+1 Phases Digital VRM Solution
  • Dual Channel DDR4:4*DIMMs XMP Memory Module Support
  • Next Generation Storage:2*PCIe 4.0 x4 M.2 Connectors
  • M.2 Thermal Guard:To Ensure M.2 SSD Performance
  • EZ-Latch:PCIe 4.0×16 Slot with Quick Release Design
  • Fast Networks:2.5GbE LAN & Intel® Wi-Fi 6E 802.11ax
  • Extended Connectivity:Rear USB-C® 10Gb/s, DP, HDMI
  • Smart Fan 6:Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
  • Q-Flash Plus:Update BIOS Without Installing the CPU, Memory and Graphics Card

Mainboard Gigabyte B760M DS3H AX DDR4

Khe Cắm PCIe Chuẩn 4.0

Gigabyte B760 đã sẵn sàng hoạt động với các thiết bị PCIe 4.0 dự kiến ​​sẽ có băng thông gấp ba lần so với các thiết bị PCIe 3.0 hiện tại. Để đạt tốc độ cao và duy trì tính toàn vẹn tín hiệu tốt, Gigabyte sử dụng PCB trở kháng thấp để mang lại hiệu suất tối đa.

Mainboard Gigabyte B760M DS3H AX DDR4 Chuẩn WiFi AX

Giải pháp không dây mới nhất 802.11ax Wi-Fi 6E với băng tần 6GHz chuyên dụng mới, cho phép hiệu suất không dây gigabit, truyền phát video mượt mà, trải nghiệm chơi trò chơi tốt hơn và tốc độ lên tới 2,4Gbps. Hơn nữa, Bluetooth 5 cung cấp phạm vi gấp 4 lần so với BT 4.2 và truyền nhanh hơn.

3,350,000₫

Mã sản phẩm: M.GG.B760M.DS3H.AX.D4
      Thương hiệu Gigabyte
      Chipset
      B760
      Hỗ trợ Socket LGA 1700
      Số khe ram 4 Slot DDR4
      Lan Realtek® 2.5GbE LAN chip (2.5 Gbps/1 Gbps/100 Mbps)
      Kết Nối Không Dây
      • WIFI a, b, g, n, ac, ax, supporting 2.4/5/6 GHz carrier frequency bands
      • Bluetooth 5.2
      • Support for 11ax 80MHz wireless standard and up to 1.2 Gbps data rate
      Internal I/O Connectors
      • 1 x 24-pin ATX main power connector
      • 1 x 8-pin ATX 12V power connector
      • 1 x CPU fan header
      • 3 x system fan headers
      • 2 x addressable LED strip headers
      • 2 x RGB LED strip headers
      • 2 x M.2 Socket 3 connectors
      • 4 x SATA 6Gb/s connectors
      • 1 x front panel header
      • 1 x front panel audio header
      • 1 x S/PDIF Out header
      • 1 x USB Type-C® header, with USB 3.2 Gen 2 support
      • 1 x USB 3.2 Gen 1 header
      • 2 x USB 2.0/1.1 headers
      • 2 x Thunderbolt™ add-in card connectors
      • 1 x Trusted Platform Module header (For the GC-TPM2.0 SPI/GC-TPM2.0 SPI 2.0 module only)
      • 1 x serial port header
      • 1 x reset button
      • 1 x Q-Flash Plus button
      • 1 x reset jumper
      • 1 x Clear CMOS jumper
      Độ Phân Giải Độ phân giải tối đa 7680 x 4320
      Bios
      • 1 x 256 Mbit flash
      • Use of licensed AMI UEFI BIOS
      • PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
      Hệ Điều Hành
      • Support for Windows 11 64-bit
      • Support for Windows 10 64-bit
      Form Factor
      Micro ATX Form Factor 24.4cm x 24.4cm
      Xem thêm cấu hình chi tiết

      Gọi đặt mua 1900 0243 (8:30 - 21:00)

      Đặc Điểm Của Mainboard Gigabyte B760M DS3H AX DDR4

      • Intel® Socket LGA 1700:Support 13th and 12th Gen Series Processors
      • Unparalleled Performance:Hybrid 6+2+1 Phases Digital VRM Solution
      • Dual Channel DDR4:4*DIMMs XMP Memory Module Support
      • Next Generation Storage:2*PCIe 4.0 x4 M.2 Connectors
      • M.2 Thermal Guard:To Ensure M.2 SSD Performance
      • EZ-Latch:PCIe 4.0×16 Slot with Quick Release Design
      • Fast Networks:2.5GbE LAN & Intel® Wi-Fi 6E 802.11ax
      • Extended Connectivity:Rear USB-C® 10Gb/s, DP, HDMI
      • Smart Fan 6:Features Multiple Temperature Sensors, Hybrid Fan Headers with FAN STOP
      • Q-Flash Plus:Update BIOS Without Installing the CPU, Memory and Graphics Card

      Mainboard Gigabyte B760M DS3H AX DDR4

      Khe Cắm PCIe Chuẩn 4.0

      Gigabyte B760 đã sẵn sàng hoạt động với các thiết bị PCIe 4.0 dự kiến ​​sẽ có băng thông gấp ba lần so với các thiết bị PCIe 3.0 hiện tại. Để đạt tốc độ cao và duy trì tính toàn vẹn tín hiệu tốt, Gigabyte sử dụng PCB trở kháng thấp để mang lại hiệu suất tối đa.

      Mainboard Gigabyte B760M DS3H AX DDR4 Chuẩn WiFi AX

      Giải pháp không dây mới nhất 802.11ax Wi-Fi 6E với băng tần 6GHz chuyên dụng mới, cho phép hiệu suất không dây gigabit, truyền phát video mượt mà, trải nghiệm chơi trò chơi tốt hơn và tốc độ lên tới 2,4Gbps. Hơn nữa, Bluetooth 5 cung cấp phạm vi gấp 4 lần so với BT 4.2 và truyền nhanh hơn.
